JJE Oil-cooled Permanent Magnet Motor

Oil-cooled Motor Systems

E-Motor Highlights

Peak Power: up to 250kW
Peak Torque: up to 500Nm
Max Speed: up to 16,000rpm

Product Advantages

High torque/Small size/High efficiency
Able to meet different assembly interface requirements
Automatic transmission oil compatible component design

System Application

These products are suitable for light/all-electric commercial vehicles, logistics vehicles etc. and pure electric, hybrid plug-in and hybrid electric passenger vehicles.

E-Motor Characteristics

3-phase permanent magnet synchronous machine
High torque density, high power density
High efficiency
Good NVH performance, optimized low electromagnetic noise
Optimized low cogging torque and low torque ripple
Automatic transmission oil compatible materials

E-Motor Specifications/Standards

DC Voltage Range: 250-1000 VDC
Conforms to GB/T 18488-2015 for mechanical shock and vibration
Oil coolant temperature: ≤80°C
Coolant type: typical DEXRON VI，or customer directed oil can also be developed
Restricted material control and flammability requirements conforming to GB/T 30512-2014，GB/T 2408-2008 HB V-0, and other EU, US standards

E-Motor Specifications

E-Motor	Peak Power	Continuous Power	Peak Torque	Continuous Torque	Max Speed	Weight (excl. housing)
SD210	66 kW	35 kW	117 Nm	51 Nm	12,500 rpm	18 kg
SD240	89 kW	45 kW	315 Nm	85 Nm	12,000 rpm	31 kg
SD220	250 kW	110 kW	500 Nm	220 Nm	11,000 rpm	47 kg
SD220	205 kW	100 kW	450 Nm	200 Nm	16,000 rpm	42 kg
