JJE SD460 Electric Motor Systems

JJE SD460 Electric Motor Systems

Number of views:
1000

JJE SD460 Electric Motor Systems

Retail price
0.0
Yuan
Market price
0.0
Yuan
Number of views:
1000
Product serial number:
Category:
Electric Machine
Quantity
-
+
Stock:
0
1
Parameters

JJE

SD460 Electric Motor Systems

Key Features

Peak Power:  up to 220 kW
Peak Torque
:  up to 3,100Nm
Maximum Speed
:  up to 3000rpm
(Performance of different motors)

Key Advantages

High torque  / High efficiency / High reliability
Satisfaction of installation requirements for different vehicle models
Silt protection / Anti condensation design



Application



The product is suitable for 9-12m electric bus, highway bus and other vehicles.



Motor Characteristics
Three phase permanent magnet synchronous motor
High torque and power density
High efficiency of motor system
Low electromagnetic noise and good NVH performance
Small cogging torque and torque ripple
Unique life-cycle maintenance free shaft seal technology, One million kilometers without leakage

Motor Specifications / Standards

Operating voltage range:  300-750 VDC
Motor protection capacity:  IP 6k9k
Shock and vibration criteria:  GB/T 18488-2015
Cooling water inlet temperature:  ≤ 65 ° C
Coolant specification:  50% / 50% glycol aqueous solution
Prohibited articles and flammability standards
GB/T 30512-2014,GB/T 2408-2008 HB V-0
External corrosion resistance:  salt spray, chemicals

Motor Specifications

Motor Peak Power Continuous Power Peak Torque Continuous
Torque
Peak Speed Motor Weight
SD460_8,50 Nm 119 kW 83 kW 850 Nm 510 Nm 3,000 rpm 187 kg
SD460_2,500 Nm 150 kW 102 kW 2,500 Nm 1,310 Nm 3,000 rpm 299 kg
SD460_3,100 Nm 220 kW 150 kW 3,100 Nm 1,500 Nm 3,000 rpm 299 kg
