JJE Series-Parallel EMDC Hybrid System
JJE Series-Parallel EMDC Hybrid System
JJE
Series-Parallel EMDC Hybrid System
EMDC Hybrid System Features
System peak output torque: up to 1,500 Nm (30s)
System peak output power: up to 220 kW
Peak output speed: up to 4,500 rpm
System efficiency: up to 94%
Five operating modes:
Electric only drive, Series hybrid drive, Parallel hybrid drive,
Engine only drive, Regenerative braking
System Advantages
High performance / fuel efficiency
Comfort/NVH significantly improved
With start-stop function, multiple working mode combinations
High reliability, maintenance-free electromagnetic clutch million kilometers
Application
JJE Parallel EMDC Hybrid System can be used in medium logistics vehicles, passenger cars, freight cars, off-road application special vehicles and other pure hybrid vehicles.
Motor Features
Permanent magnet synchronous motor
High torque and power density
High efficiency
Low electromagnetic noise and low NVH
Small cogging torque and torque fluctuation
Unique lifetime maintenance-free shaft seal technology
Parallel EMDC Hybrid System Features
Maintenance-free automatic clutch
Five operating modes
Efficient recovery brake
Drive motor recovery brake, dual motor recovery brake
Downhill mode: drive motor to recover braking, ISG reverse drag
Optional Motor Parameters
| Motor | Peak Power | Continuous Power | Peak Torque | Continuous Torque | Maximum Speed | Weight |
| ISG:SD290_250 Nm TM:SD290_850 Nm |
58 kW 144 kW |
27 kW 73 kW |
250 Nm 850 Nm |
130 Nm 350 Nm |
4,500 rpm | 260 kg |
| ISG:SD290_250 Nm TM:SD290_1,250 Nm |
58 kW 174 kW |
27 kW 86 kW |
250 Nm 1,250 Nm |
130 Nm 520 Nm |
4,500 rpm | 270 kg |
| ISG:SD290_250 Nm TM:SD220_580 Nm |
58 kW 220 kW |
27 kW 115 kW |
250 Nm 580 Nm |
130 Nm 285 Nm |
4,500 rpm | 235 kg |
Note: Voltage, water temperature and other differences will lead to changes in motor parameters.
